Sharp MX-7090N / MX-8090N Photocopier
Have a Question about this product?
Copy Speed: 70/80ppm (A4) 41/45ppm (A3) 39/43 (SRA3)
First Copy Time (OC/SPF): Colour: 5.6/5.1 sec; B/W: 4.0/3.7 sec
The MX7090/8090N Sharp photocopiers is built for fast, high-volume printing in large-scale settings. Whether at a large company, government office, university, or research centre, it produces beautiful colour documents with ease.
Refined Sharp MFD technology delivers an optimal balance of productivity, quality, and user-friendly operation and a powerful Fiery® printer server option adds further versatility to the MX7090/8090N that can already handle a wide variety of documents.
15.4-Inch Colour LCD Touchscreen
A large, high-resolution touchscreen provides an easy-to-use graphical interface featuring a clean design, simplified Easy UI mode, and integrated operation guide. For easy viewing at the desired angle, the control panel can be tilted front to back and side to side, and the panel’s support arm can be rotated.
Fiery® Print Server
Paired with an industry-leading EFI™ Fiery print server, the MX7090/8090N becomes a powerful integrated solution for managing professional in-plant and busy on-demand printing environments. Two options are available to match your needs: the multifunctional MX-PE13 external server, or the more affordable basic MX-PE14 embedded server.
Direct Printing/Scanning
Insert a USB drive into the MX7090/8090N and a print/scan command screen will automatically pop up on the LCD. Right away you can print files from the USB drive—which are displayed as thumbnails—or you can scan documents directly to the USB drive.
Paper Setting Registration
The MX7090/8090N’s Paper Setting Registration function allows instant recall of pre-registered media profiles. It stores up to 1,000 media profiles that include front-to-back registration settings, data on fusing temperature, and data on the type and weight of paper used.
Link to Cloud Services*
An MX7090/8090N doesn’t just connect to your local server. It also connects with cloud services directly from the MFD’s control panel. You can upload scanned data to Google Drive, Box, OneDrive for business, or SharePoint Online—or print directly from any of them. *MXAMX2 is required.
Link with Mail Servers
Scanned data can be conveniently sent via your regular Gmail™ or Microsoft Exchange/Online account. Sending e-mail is as easy as choosing a recipient from your address book on the mail server.
DDS Filters
| Print Speed | 70ppm - 80ppm |
General Info
| Print Type | Colour |
| User Interface | Colour 15.4" LCD Touch-Screen |
| Product Environment | Light production and Department |
| Original Paper Size | Max A3 |
| Printed Paper Size | Tray: A3W-A5R, Opt: Bypass: 13” x 19.2”& SRA3 -A5R [MX-MF10] |
| Standard Paper Capacity | 3,100 (1200-sheets, 800 sheets, 500 sheets x 2, 100-sheet Multi bypass) |
| Maximum Paper Capacity | 13,500 (1200 + 800 sheets, 500 sheets x 2, 500 sheet bypass, 2,500 sheets x 4 LCT) |
| Paper Weight | Tray 1 & 2: 60-105gsm, Tray 3 & 4: 60-220gsm, LCC: 60-220gsm, LCT (Air): 55-300gsm, Bypass Tray: 55-300gsm [MX-MF10], 55-220gsm [MX-MF11] |
| Output Capacity | Optional MXTU14 250-sheet centre tray or Finisher is required, additional MXTR14 100-sheet right tray |
| Warm-up Time | 90 sec |
| Resolution (Equivalent) | 9,600 (equivalent) x 600 dpi (Colour Copy), 1200x1200 dpi (B/W Copy), 1200 x 1200 dpi ( Printer ) |
| Memory | 6 GB (STD & Max) |
| HDD Capacity | 1TB |
| Duplex | Std. (60 – 300 g/m2) |
| Dimension (W x D x H) | 982 x 768 x 1,530 mm |
| Weight (kg) | 224.000000 |
| Sharp OSA | 5.1 |
Copier
| Copy Speed | 70/80ppm (A4) 41/45ppm (A3) 39/43 (SRA3) |
| E-Sort / SOPM | Yes / Yes |
| First Copy Time (OC) | Colour: 5.6/5.1 sec; B/W: 4.0/3.7 sec |
| Continuous Copy | Max 9,999 |
| Scan Resolution | Colour: 600 x 600 dpi, B/W: 600 x 400 dpi, 600 x 600 dpi |
| Zoom Range | 25 - 400% (DSPF 25 - 200%) in 1% increments |
Environmental
| Power Supply/Consumption | Max. 3.84 kW |
| TEC Value (Measured) | 70ppm: 7.9 kWh; 80ppm: 8.8 kWh |
| Noise | Standby: 52dB, Operating: 78dB |
Document Feeder
| Document Feeder | Std: DSPF |
| Original Capacity | Max 150 sheets |
| First Copy Time | Colour: 9.2 sec, B/W: 6.5 sec |
| Scan Speed | Copy/Image Send Mode: 100 opm (1-sided), 200 opm (2-sided). |
Filing
| Quick/Main Folder | Quick Folder: Max 10,000 pages, Main/Custom Folder: Max 35,000 pages or 5,000 files |
| Preview Thumbnails | Supported (includes Advanced Edit Mode) |
Printer Spec
| Print Speed (Max) | 70/80ppm (A4) 41/45ppm (A3) 39/43 (SRA3) |
| PDL (Emulation) | STD: PCL6 emulation, Adobe® PostScript® 3™ |
| Interface | USB2.0, 10Base-T / 100Base-TX / 1000BaseT |
| Wireless LAN | N/A |
| Protocol | TCP/IP (IPv4, IPv6) |
| Supported OS | Windows® 7*, Windows® 8.1*, Windows® 10*, Windows® Server 2008* / 2008R2 / 2012 / 2012R2 / 2016 (*32/64bit). Mac OS 10.6.x, 10.7.x, 10.8.x, 10.9.x, 10.10.x, 10.11.x, 10.12.x, 10.13.x |
| Utility Software (Download) | Status Monitor |
Network Scanner
| Resolution | Push scan: 100, 150, 200, 300, 400, 600 dpi Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi 50 to 9,600 dpi via user setting |
| Format | Mono: TIFF, XPS, PDF, PDF/A, Encrypted PDF, Searchable PDF, Office Format (docx, xlsx, pptx), TXT, RTF & UTF-8. Colour: TIFF, JPEG, XPS, PDF, PDF/A, Encrypted PDF, Searchable PDF, Compact PDF, Office Format (docx, xlsx, pptx), TXT, RTF & UTF-8. |
| Destination | FTP, E-Mail, SMB Folder, USB, HDD, TWAIN / WIA compliant |
| User Registration | Max 2,000 (one touch), 500 (group) |
| Utility Software (Download) | None |
Facsimile
| Model | Not Supported |
| Communication Protocol | N/A |
| Transmission Speed | N/A |
| Compression | N/A |
| Inbound Routing | N/A |
| PC Fax | N/A |
| MX-7090N MX-8090N |
|---|
 |
|
| Specifications | |
| First Copy Time | 5.6 sec color/4 sec black |
| Multicopy (Ltr/Lgl/Ldgr) | 70 cpm color/70 cpm black |
| Warm-up Time | 90 sec |
| Std Paper Source(s) | 500/500/800/1,200 sheets |
| Paper Weights | 60 to 220 gsm |
| Max Paper Capacity | 13,500 sheets |
| Output Size (Min/Max) | A5/A3W |
| Copy Resolution | 600 x 600 dpi |
| System Memory (Std/Max) | 5-GB RAM, 8-TB HD/5-GB RAM, 8-TB HD |
| Document Feeder | Std DSPF |
| Document Feeder Capacity | 150 orig |
| Printer | |
| Mobile Print Support | Yes |
| Speed | 70 ppm color/70 ppm black |
| Print from USB | Yes (DOCX, JPEG, PCL, PDF, compact PDF/A1, encrypted PDF, PNG, PPTX, PRN, PS, TIFF, TXT, XLSX) |
| Resolution | 1200 x 1200 dpi |
| Scanner | |
| Scan Speed | 200 ipm color, 200 ipm black |
| Max Resolution | 600 x 600 dpi |
| File Formats Supported | DOCX, JPEG, PDF, PDF/A, compressed PDF, encrypted PDF, searchable PDF, PPTX, RFT, TIFF, TXT, XLSX, XPS |
| OCR Software | std embedded OCR software |
 |
 |
|
| Specifications | ||
| First Copy Time | 4.9 sec color/3.7 sec black | 7.5 sec color/5.5 sec black |
| Multicopy (Ltr/Lgl/Ldgr) | 65 cpm color/65 cpm black | 65 cpm color/65 cpm black |
| Warm-up Time | 35 sec | 43 sec |
| Std Paper Source(s) | 500/500/1,000/1,500 sheets | 2,500/550/550 sheets |
| Paper Weights | 52 to 256 gsm | 52.3 to 256 gsm |
| Max Paper Capacity | 6,650 sheets | 8,100 sheets |
| Output Size (Min/Max) | A6/SRA3 | A5/330 x 487 |
| Copy Resolution | 600 x 600 dpi | 600 x 600 dpi |
| System Memory (Std/Max) | 4-GB RAM, 250-GB HD/4-GB RAM, 250-GB HD | 4-GB RAM, 640-GB HD*/4-GB RAM, 640-GB HD* |
| Document Feeder | Std DSPF | Std DSPF |
| Document Feeder Capacity | 300 orig | 220 orig |
| Printer | ||
| Mobile Print Support | Yes (Apple AirPrint, Google Cloud Print, Konica Minolta Mobile Print, Mopria Print Service, Wi-Fi Direct) | Yes |
| Speed | 65 ppm color/65 ppm black | 65 ppm color/65 ppm black |
| Print from USB | Yes (DOCX, JPEG, PDF, compact PDF, PPML, PPTX, TIFF, VDX, XLSX, XPS, compact XPS, ZIP) | Yes |
| Resolution | 1200 x 1200 dpi | 1200 x 4800 dpi |
| Scanner | ||
| Scan Speed | CCD/120 ipm color, 120 ipm black | CCD/120 ipm color, 120 ipm black |
| Max Resolution | 600 x 600 dpi | 600 x 600 dpi |
| File Formats Supported | DOCX, searchable DOCX, JPEG, PDF, PDF/A, PDF/A 1a and 1b, compact PDF, encrypted PDF, linearized PDF, searchable PDF, PPTX, searchable PPTX, TIFF, XLSX, searchable XLSX, XPS, compact XPS | JPEG, PDF, PDF/A, compact PDF, TIFF |
| OCR Software | Opt i-Option License kit searchable PDF | Opt OCR unit |
